-27%
- 8ΓΒ 10/100/1000 Mbps RJ45 ports.
- 4Γ PoE+ ports transfer data and power on the cables
- Works with IEEE 802.3af/at compliant PDs
- Plug and Play, no configuration and installation required
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE power up to 30 W for each PoE port
- Supports PoE power up to 64 W for all PoE ports*
| Weight | 2.5 lbs |
|---|---|
| Dimensions | 11 × 9 × 3 in |
| HARDWARE FEATURES | |
|---|---|
| Interface | 8Γ 10/100/1000 Mbps RJ45 Ports AUTO Negotiation AUTO MDI/MDIX |
| Network Media | β’ 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) β’ EIA/TIA-568 100Ξ© STP (maximum 100m) β’ 100BASE-TX: UTP category 5, 5e cable (maximum 100m) β’ EIA/TIA-568 100Ξ© STP (maximum 100m) β’ 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) β’ EIA/TIA-568 100Ξ© STP (maximum 100m) |
| Fan Quantity | Fanless |
| Physical Security Lock | Yes |
| External Power Supply | External power adapter (Output: 54VDC / 1.3A) |
| Packet Forwarding Rate | 11.904 Mpps |
| PoE Ports (RJ45) | β’ Standard: 802.3 af/at compliant β’ PoE Ports: ports 1β4 β’ Power budget for all PoE ports: 64 W |
| Mac Address Table | 4K |
| Jumbo Frame | 16 KB |
| Switching Capacity | 16 Gbps |
| Dimensions ( W x D x H ) | 6.7 Γ 3.9 Γ 1.1 in (171Γ98Γ27 mm) |
| Max Power Consumption | β’ 5.4 W (with no PD connected) β’ 75 W (with 64W PD connected) |
| Max Heat Dissipation | β’ 18.4 BTU/h (with no PD connected) β’ 225.8 BTU/h (with 64 W PD connected) |
| SOFTWARE FEATURES | |
|---|---|
| Transmission Method | Store-And-Forward |
| Advanced Functions | β’ Compatible With IEEE 802.3af/at Compliant PDs β’ IGMP Snooping β’ Mac Address Auto-Learning And Auto-Aging β’ IEEE802.3x Flow Control β’ 802.1p/DSCP QoS |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Contents | β’ TL-SG1008P β’ Power Adapter β’ Installation Guide |
| Environment | β’ Operating Temperature: 0β40 β (32β104 β); β’ Storage Temperature: -40β70 β (-40β158 β) β’ Operating Humidity: 10β90% RH non-condensing β’ Storage Humidity: 5β90% RH non-condensing |
