Protech 15U Server Rack Cabinet – 800mm (32″) Deep, 19″ Floor Standing Network Cabinet with 4 Cooling Fans, Glass Door & Wheels


Call For PurchaseΒ

$ 374.99 $ 450.00

Protech 15U 800mm Deep Floor Standing Server Rack Cabinet – 19-Inch Network Rack with Cooling Fans & Wheels

Organize, protect and manage your networking, IT and security equipment with the Protech 15U Floor Standing Server Rack Cabinet, featuring an 800mm (approximately 32-inch) depth, lockable tempered-glass front door and professional 19-inch rack-mount design.

Designed for home networks, small offices, commercial installations and CCTV security systems, this cabinet provides a centralized enclosure for compatible network switches, patch panels, DVRs, NVRs, routers and audio/video equipment.

The cabinet includes four preinstalled 110V cooling fans, one full-size shelf, adjustable mounting rails, removable lockable side panels, a vented rear door and caster wheels.

Its EIA-310-D compliant rack design supports compatible standard 19-inch rack-mounted equipment.

Key Features

  • 15U Rack Capacity: Provides 15 rack units for installing compatible networking and security equipment.
  • 800mm Cabinet Depth: Approximately 32 inches of external cabinet depth.
  • Standard 19-Inch Rack Width: EIA-310-D compliant mounting configuration.
  • Lockable Tempered-Glass Front Door: Provides visibility and controlled access to installed equipment.
  • Reversible Front Door: Flexible installation to suit the room layout.
  • Vented Rear Door: Supports ventilation and airflow.
  • Lockable Removable Side Panels: Convenient access for installation and maintenance.
  • Four Preinstalled 110V Fans: Active ventilation for installed equipment.
  • One Full-Size Shelf Included: Supports compatible non-rackmount equipment.
  • Heavy-Duty Adjustable Rails: Maximum supplier-listed rail adjustment of 24 inches.
  • Caster Wheels Included: Suitable for floor-standing installations.
  • Top and Bottom Cable Openings: Helps organize power and network cables.
  • 50 Sets of Cage Nuts and Bolts: Mounting hardware included.
  • 500kg Load Capacity: Manufacturer-listed capacity of approximately 1102 lbs.
  • One-Year Manufacturer Warranty: Subject to applicable warranty conditions.
  • Ships Unassembled: Supplied in three cartons.

15U Rack-Mount Equipment Storage

The Protech 15U cabinet provides organized mounting space for compatible 19-inch equipment.

It is suitable for:

  • Network switches
  • Patch panels
  • Routers and firewalls
  • CCTV DVR and NVR recorders
  • Rack-mounted servers
  • Audio/video equipment
  • Power distribution accessories
  • Networking and telecommunications equipment

The 15U format is particularly useful for installations requiring more rack space than compact wall-mounted cabinets while maintaining a manageable floor-standing footprint.

800mm Deep Server Cabinet

The cabinet features an external depth of approximately 800mm (32 inches).

The supplier lists an internal assembled depth of 24 inches, providing space for compatible equipment and cabling.

Before purchasing, verify the dimensions of your servers, recorders, shelves and other devices to ensure sufficient installation clearance.

Lockable Tempered-Glass Front Door

The cabinet features a lockable tempered-glass front door, allowing installed equipment to remain visible while helping restrict unauthorized access.

The reversible design provides flexibility when positioning the cabinet in offices, server rooms or equipment areas.

Vented Rear Door and Lockable Side Panels

The rear door features ventilation openings to support airflow through the cabinet.

Removable, lockable side panels allow easier access to internal equipment, wiring and mounting hardware.

These features simplify routine installation and maintenance tasks.

Four Preinstalled 110V Cooling Fans

The Protech 15U server cabinet includes four preinstalled 110V cooling fans.

These fans help circulate air and manage heat generated by networking, security and other electronic equipment.

Actual cooling performance depends on equipment heat output, ambient temperature and available ventilation clearance.

One Full-Size Equipment Shelf Included

The cabinet includes one full-size shelf for compatible devices that cannot be mounted directly to the rack rails.

This is useful for supporting smaller network devices, security equipment and other suitable accessories.

The shelf’s individual load capacity has not been specified.

Adjustable Heavy-Duty Mounting Rails

The included heavy-duty mounting rails provide a maximum supplier-listed adjustment of 24 inches.

This allows the rack configuration to be adapted to compatible equipment mounting requirements.

Always verify the required rail spacing, equipment depth and mounting hardware before installation.

Floor Standing Cabinet with Wheels

The cabinet includes caster wheels for floor-standing use.

The wheels help with positioning the cabinet during installation and maintenance.

For loaded installations, confirm the appropriate wheel, leveling and floor-loading requirements before moving or positioning the cabinet.

Top and Bottom Cable Management

Cable openings at the top and bottom of the enclosure provide convenient routing for:

  • Ethernet cables
  • Fibre-optic cables
  • Power cables
  • CCTV camera wiring
  • Patch panel connections
  • Audio/video cables

Organized cable routing can help improve accessibility and simplify future maintenance.

EIA-310-D Compliant Design

The Protech 15U cabinet is described as EIA-310-D compliant, supporting compatible standard 19-inch rack-mounted equipment.

Check the mounting depth, weight and ventilation requirements of each device before installation.

Technical Specifications

Specification Details
Brand Protech
Product Type Floor Standing Network / Server Rack Cabinet
Rack Capacity 15U
External Depth 800mm / Approximately 32 Inches
Rack Mounting Width 19 Inches
Rack Standard EIA-310-D
Colour Black
Front Door Lockable Tempered Glass
Front Door Orientation Reversible
Rear Door Vented
Side Panels Removable and Lockable
Cooling Fans 4 Preinstalled
Fan Voltage 110V
Included Shelves 1 Full-Size Shelf
Mounting Rails Heavy-Duty Adjustable
Maximum Listed Rail Adjustment 24 Inches
Wheels Included
Cable Openings Top and Bottom
Cage Nuts and Bolts 50 Sets
Maximum Listed Load Capacity 500kg / 1102 lbs
Assembly Required
Shipping Cartons 3
Manufacturer Warranty 1 Year

Cabinet Dimensions

Measurement Dimensions
External Width 23.5 Inches
External Depth 32 Inches
External Height with Wheels 33.5 Inches
External Height without Wheels 30.5 Inches
Internal Width 19 Inches
Internal Depth 24 Inches
Internal Height 26 Inches

Dimensions are based on the supplied product specifications and may be approximate.

Package Includes

  • 1 Γ— Protech 15U 800mm Deep Server Cabinet (Unassembled)
  • 1 Γ— Lockable Tempered-Glass Front Door
  • 1 Γ— Vented Rear Door
  • Removable Lockable Side Panels
  • 4 Γ— Preinstalled 110V Cooling Fans
  • 1 Γ— Full-Size Shelf
  • Adjustable Rack Mounting Rails
  • Caster Wheels
  • 50 Γ— Sets of Cage Nuts and Bolts

Shipping Information

The cabinet ships unassembled in three cartons.

Carton Dimensions (Inches) Listed Weight
Carton 1 28 Γ— 24 Γ— 5 23 lbs
Carton 2 33 Γ— 24 Γ— 5 52 lbs
Carton 3 31 Γ— 24 Γ— 10 31 lbs
Total 3 Cartons 106 lbs

Shipping costs and delivery arrangements should be confirmed before purchase.

Ideal Applications

  • Small business server rooms
  • CCTV and security system installations
  • Office networking equipment
  • Network switch and patch panel installations
  • Telecommunications equipment
  • Audio/video equipment
  • IT infrastructure
  • Commercial network installations
  • Home networking setups

Installation and Compatibility Notes

  • Assembly is required before use.
  • Ensure adequate floor space and installation clearance.
  • Verify equipment depth and rail compatibility.
  • Confirm electrical requirements for the four 110V cooling fans.
  • Maintain suitable airflow around the cabinet.
  • Check floor-loading and weight distribution requirements.
  • Confirm the rated capacity of the caster wheels before loading or moving the cabinet.
  • The cabinet ships in three cartons.

Buy Protech 15U Server Rack Cabinets in Canada

Shop the Protech 15U 800mm Deep Floor Standing Server Rack Cabinet at Tech Vision Electronics.

We supply server racks, network cabinets, rack shelves, patch panels, PoE switches, cable management accessories and CCTV security equipment for residential and commercial installations.

Call for Purchase: Contact our team for product availability, shipping arrangements and assistance.

Tech Vision Electronics
1261 Kennedy Road, Unit 4
Scarborough, Ontario M1P 2L4
Phone: 416-551-7334
Website: www.techvisionelectronics.com

SKU: PT-FC15U800 Category:
Weight 150 lbs
Dimensions 42 × 42 × 20 in
Model Number

PT-FC15U800

Product Size

23.5X32X33.5 INCHS(W X D XH)

Rack Size

15U

Colour

Black

Materials

Metal, Glass

Back Door

Yes, Vented Door

Side Panels

Yes & Removable

Locks

Round Lock on side panels and front door

Mounting Rails

Adjustable ,Max distance between rails 24 inches

Cable Slots

4 on top and 4 at bottom

Wall Mountable

NO

Wheels

Yes

Fan

4 fans Included

Shelfs

1 shelfs Included

Mounting Harware

Included

Assembly Required

Yes

Weight Capacity

500kgs / 1102 lbs

Warranty

1 Year Manufacturer's Limited Warranty
