Camera |
Image Sensor |
1/3″ Progressive Scan CMOS |
Max. Resolution |
2560 × 1440 |
Min. Illumination |
Color: 0.001 Lux @(F1.0, AGC ON), B/W: 0 Lux with white light |
Shutter Speed |
1/3 s to 1/100, 000 s |
Day & Night |
24 Colorful imaging |
Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
Lens |
Lens Type |
Fixed focal lens, 2.8 |
Focal Length & FOV |
2.8 mm, horizontal FOV 96.5°, vertical FOV 50.8°, diagonal FOV 113.9° |
Lens Mount |
M12 |
Iris Type |
Fixed |
Aperture |
F1.0 |
DORI |
DORI |
2.8 mm, D: 64.0 m, O: 25.4 m, R: 12.8 m, I: 6.4 m |
Illuminator |
Supplement Light Type |
White light |
Supplement Light Range |
Up to 30 m |
Smart Supplement Light |
Yes |
Video |
Main Stream |
50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 20 fps (2560 × 1440) 30 fps (1920 × 1080, 1280 × 720) |
Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
Video Compression |
Main stream: H.265+/H.264+/H.265/H.264
Sub-stream: H.265/H.264/MJPEG |
Video Bit Rate |
32 Kbps to 8 Mbps |
H.264 Type |
Baseline Profile/Main Profile/High Profile |
H.265 Type |
Main Profile |
Region of Interest (ROI) |
1 fixed region for main stream |
Network |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP,
IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
Simultaneous Live View |
Up to 6 channels |
API |
Open Network Video Interface, ISAPI |
User/Host |
Up to 32 users. 3 levels: administrator, operator and user |
Client |
iVMS-4200, Hik-Connect |
Web Browser |
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
Image |
Image Settings |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client
software or web browser. |
Day/Night Switch |
Day, Night, Auto, Schedule |
Wide Dynamic Range (WDR) |
120 dB |
Image Enhancement |
BLC, 3D DNR |
Interface |
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
Event |
Basic Event |
Motion detection, video tampering alarm, exception |
Linkage |
Upload to FTP, notify surveillance center, send email, trigger capture |
General |
Power |
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
Linkage Method |
Upload to FTP, notify surveillance center, send email, trigger capture |
Camera Material |
Metal & Plastic |
Camera Dimension |
Ø112 mm × 88.4 mm (Ø4.41″ × 3.48″) |
Package Dimension |
150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″) |
Camera Weight |
Approx. 370 g (0.8 lb.) |
With Package Weight |
Approx. 640 g (1.4 lb.) |
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
Language |
English, Ukrainian |
General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address
filter |
Firmware Version |
V5.5.123 |
Approval |
EMC |
FCC-SDoC: 47 CFR Part 15, Subpart B;
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-
4: 2011 +A1: 2014;
RCM: AS/NZS CISPR 32: 2015;
KC: KN 32: 2015, KN 35: 2015 |
Protection |
IP67: IEC 60529-2013 |
Model |
NVR-208MH-C/8P |
Video and Audio |
IP video input |
8-ch |
Up to 8 MP resolution |
Incoming bandwidth |
80 Mbps |
Outgoing bandwidth |
80 Mbps |
HDMI output |
1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x
1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz |
VGA output |
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
Video output mode |
HDMI/VGA simultaneous output |
CVBS output |
N/A |
Audio output |
1-ch, RCA (Linear, 1 KΩ) |
Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
Decoding |
Decoding format |
H.265+/H.265/H.264+/H.264 |
Recording resolution |
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF |
Synchronous playback |
8-ch |
Capability |
1-ch@8 MP (30 fps)/5-ch@1080p (30 fps) |
Stream type |
Video, Video & Audio |
Audio compression |
G.711ulaw/G.711alaw/G.722/G.726 |
Network |
Remote connection |
64 |
Network protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP
™, HTTP, HTTPS |
Network interface |
1, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
PoE |
Interface |
8, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
Power |
≤ 80W |
Supported standard |
IEEE 802.3 af/at |
Auxiliary Interface |
SATA |
2 SATA interfaces |
Capacity |
Up to 8 TB capacity for each disk |
USB interface |
Front panel: 1 × USB 2.0 ; Rear panel: 1 × USB 2.0 |
General |
Power supply |
48 VDC, 2.5 A |
Consumption
(without HDD and PoE off) |
≤ 15 W |
Working temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
Working humidity |
10% to 90% |
Dimension (W × D × H) |
385 × 315 × 52 mm (15.2″ × 12.4″ × 2.0″) |
Weight (without HDD) |
≤ 2.6 kg (5.7 lb) |
