Specification |
Details |
Image Sensor |
1/2.8″ Progressive Scan CMOS |
Max. Resolution |
3840 × 2160 |
Min. Illumination |
Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR |
Shutter Time |
1/3 s to 1/100,000 s |
Day & Night |
IR cut filter |
Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
Lens |
Lens Type |
Fixed focal lens, 2.8 mm |
Focal Length & FOV |
2.8 mm, horizontal FOV 108°, vertical FOV 60°, diagonal FOV 127° |
Lens Mount |
M12 |
Iris Type |
Fixed |
Aperture |
F2.0 |
DORI |
DORI |
D: 81 m, O: 32 m, R: 16 m, I: 8 m |
Illuminator |
Supplement Light Type |
IR |
Supplement Light Range |
Up to 30 m |
Smart Supplement Light |
Yes |
IR Wavelength |
850 nm |
Video |
Main Stream |
50 Hz: 12.5 fps (3840 × 2160), 20 fps (2592 × 1944), 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 15 fps (3840 × 2160), 20 fps (2592 × 1944), 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG |
Video Bit Rate |
32 Kbps to 16 Mbps |
H.264 Type |
Baseline Profile/Main Profile/High Profile |
H.265 Type |
Main Profile |
Bit Rate Control |
CBR/VBR |
Region of Interest (ROI) |
1 fixed region for main stream |
Network |
Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, security audit log, TLS 1.2, host authentication (MAC address) |
Simultaneous Live View |
Up to 6 channels |
API |
Open Network Video Interface (Profile S), ISAPI, SDK |
Protocols |
TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, 802.1x, SMTP |
User/Host |
Up to 32 users |
Client |
iVMS-4200, HiLookVision |
Web Browser |
Plug-in required live view: IE 10, IE 11
Local service: Chrome 57.0+, Firefox 52.0+ |
Image |
Wide Dynamic Range (WDR) |
120 dB |
SNR |
≥ 52 dB |
Day/Night Switch |
Day, Night, Auto, Schedule |
Image Enhancement |
BLC, HLC, 3D DNR |
Image Settings |
Mirror, rotate, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
Privacy Mask |
4 regions of privacy mask |
Interface |
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
Event |
Basic Event |
Motion detection, video tampering alarm, exception |
Linkage |
Notify surveillance center, trigger capture |
General |
Power |
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
Material |
Metal & Plastic |
Dimension |
Ø110 mm × 95.2 mm (Ø4.3″ × 3.8″) |
Package Dimension |
150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″) |
Weight |
Approx. 320 g (0.7 lb.) |
With Package Weight |
Approx. 530 g (1.2 lb.) |
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing) |
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing) |
Language |
English, Ukrainian |
General Function |
Anti-flicker, heartbeat, password protection, password reset via email |
Approval |
EMC |
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014);
RCM (AS/NZS CISPR 32: 2015) |
Safety |
CB (IEC 62368-1:2014+A11);
CE-LVD (EN 62368-1:2014/A11:2017) |
Environment |
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006) |
Protection |
IP67 (IEC 60529-2013) |
