-Manage access control and intercom functions in one device
-IP65 & IK09 protections, as well as increased stability with zinc alloy materials
-Supports multiple authentication methods (card, PIN, etc.)
-Remote control via the Hik-Connect mobile app
-Connects to external access controller via Wiegand protocol
-Video intercom via SIP protocol. Supported SIP server: Brekeke, miniSipServer,FreePBX, Asterisk, 3CX, ELASTIX, and PBX ware
-RS-485 communication for connecting external card reader and calling elevator
-Supports AP mode
-Press calling button to call one of the following objects: management center, indoor station, specified indoor station, or Hik-Connect App
-Supports up to 256 GB SD card memory
-Supports PIN settings under platform mode and local mode
-Setting the priority of wired network and wireless network is available
| System | |
| Operating system | Linux |
| Video | |
| Lens | 1 |
| Video compression standard | H.264 and H.265 |
| Resolution | 2 MP |
| FOV | HFOV = 110°; VFOV = 81°; DFOV = 122° |
| Video standard | PAL (Default) and NTSC |
| Network | |
| Wired network | 10 M/100 M self-adaptive |
| Wi-Fi | Support |
| Interface | |
| Network interface | 1 |
| Lock control | 1 |
| Exit button | 1 |
| Door contact input | 1 |
| Alarm input | 1 |
| Alarm output | 1 |
| TAMPER | 1 |
| RS-485 | 1 |
| Wiegand | 1 (output) |
| SD Card Slot | 1 |
| Capacity | |
| Card capacity | 100,000 |
| Event capacity | 300,000 |
| Authentication | |
| Card type | M1 card;DESfire card |
| Card reading distance | 0 ~ 3 cm |
| General | |
| Power supply | 1 A (12 VDC to 24 VDC) |
| Power consumption | ≤12 W |
| Working temperature | -40 ℃ ~ +70 ℃ (-40 °F ~ +158 °F) |
| Protective level | IK09, IP65 |
| Language | Arabic, English, French, Indonesian, Italian, Portuguese (Brazil), Russian, Spanish (Europe), Thai, Ukrainian, Vietnamese, German, Polish, Hungarian, Czech, Romanian, Bulgarian, Croatian, Serbian, Greek, Slovak, Portuguese, Dutch, and Turkish |
| Function | |
| Two-way audio | Support |
| Video intercom | Support |
| Hik-Connect | Support |
| Weight | 6 lbs |
|---|
