- Support H.265+ POE 4K IP camera and PTZ IP camera
- H.265+ is newer and more advanced than H.265 and H.264 (To enable H.265+ requires both the NVR and the camera to have H.265+ capability)
- Compatible with H.265 / H.265+ / H.264 / H.264+
- Including original factory installed 2TB HDD, 1 SATA interfaces up to 6TB HDD support
- One year replacement warranty by seller, if you encounter any problems while using this NVR, please feel free to contact us, we provide 24/7 technical support.
- Supports hik-connect, ivms-4200 client software and Hikvision search active device protocol (SADP) tool
Video/Audio Input
IP video input: | 8-ch
Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth: | 80Mbps
Outgoing bandwidth: | 80Mbps
Video/Audio Output
HDMI Output: 1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Recording Resolution: 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
VGA Output: 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Decoding
Live view / Playback: | 8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability: | 8-ch@1080P
Hard Disk
SATA: | 1 SATA interfaces for 1 HDDs
Capacity: | Up to 8TB capacity for each HDD
External Interface
USB Interface: | 2, USB2.0
>
POE
Interface: | 8 independent 10 /100 Mbps PoE Ethernet interfaces
General
Power Supply: | 100 to 200 VAC
Consumption(without hard disk and POE): | ≤ 15 W
Working Temperature: | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
Working Humidity: | 10 % ~ 90 %
Chassis: | 385 mm chassis
Dimensions: | 385 mm × 315 mm × 52 mm (15.2″× 12.4″ × 2.0″)
Weight(without HDD): | ≤ 3 kg (6.6 lb)
